1 to 15 of 15 items

Page 1

Stock Code: 561198

Intellinet 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports - IEEE 802.3at/af Power over Ethernet (PoE+/PoE) Compliant, 374 W, Endspan, 19 Inch Rackmount, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Intellinet 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports - IEEE 802.3at/af Power over Ethernet (PoE+/PoE) Compliant, 374 W, Endspan, 19" Rackmount, Retail Box, 1 year Limited Warranty

Product Overview:
The Intellinet Network Solutions 16-Port Gigabit Ethernet PoE+ Web-Managed Switch with 2 SFP Ports (561198) is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with sixteen Gigabit Ethernet ports, all of which support 802.3at/af Power over Ethernet (PoE/PoE+), this switch can power Wireless LAN access points and bridges, VoIP (Voice over Internet Protocol) telephones, IP surveillance cameras and more while delivering network speeds of up to 1,000 Mbps.

Highlights:
• Provides power and data connection for up to 16 PoE network devices
• Save installation cost by delivering data and power over existing network cables
• 10/100/1000 auto-sensing ports automatically detect optimal network speeds
• Two small form-factor pluggable GBIC module slots (SFP)
• IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
• Power output up to 30 watts per port*
• PoE power budget of 374 watts
• 36 Gbps switch fabric
• Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras, etc.)
• Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
• All RJ45 ports with Auto-MDIX and NWay auto-negotiation support
• Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification
• PoE management functions include PoE port settings, priority, power-on delay, scheduled PoE device restart and PoE device monitoring
• The Powered Device Monitor feature (PDM) restarts any connected PoE device that fails to respond or send out network traffic
• SNMP Management and Remote Monitoring (RMON)
• SNMP V1, V2C, V3 with RMON groups 1, 2, 3 & 9
• IPv4/v6 dual protocol
• Supports VLAN (tag-based and port-based)
• Provides IEEE 802.1x port-based security
• Supports link aggregation (trunking)
• Supports bandwidth control per port
• Supports port mirroring
• Supports two types of QoS: port-based and DSCP
• Broadcast storm control with multicast packet rate settings
• 512 kBytes buffer memory
• Supports 8k MAC address entries
• Supports jumbo frames up to 9 kBytes
• Supports Rapid Spanning Tree/Spanning Tree protocol
• Store and forward switching architecture
• Full/half duplex operation
• IEEE 802.3x flow control for full duplex
• Configuration via Web browser, Telnet or SSH
• Remote Reboot/restart
• LEDs for power, link/activity and PoE
• Two high-volume cooling fans ensure perfect ventilation

Stock Code: TL-SG2428P

TP-Link JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Power and manage your network with the TP-Link JetStream 28-Port Gigabit Smart Switch.This versatile switch offers 24 PoE+ ports, delivering power and data to devices like IP cameras and VoIP phones. Benefit from advanced features like centralized cloud management, robust security, and quality of service for optimized network performance.

Specifications

•Product code: TL-SG2428P

•Description: TP-Link JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+

•24× 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)

•4× Gigabit SFP Slots

•Standard: 802.3at/af compliant

•Dimensions ( W x D x H ) 17.3 × 8.7 × 1.73 in (440 × 220 × 44 mm)

•Mounting Rack Mountable

•Max Power Consumption

•32.1 W (110 V/ 60 Hz with no PD connected)

•308.6 W (110 V/ 60 Hz with 250 W PD connected)

•Switching Capacity 56 Gbps

•Bandwidth/Backplane 56 Gbps

•Packet Forwarding Rate 41.7 Mpps

•MAC Address Table 8K

•Packet Buffer Memory 4.1 Mbit

•Jumbo Frame 9KB

•Support 802.1p CoS/DSCP priority

•Support 8 priority queues

•Queue scheduling: SP, WRR, SP+WRR

•Port/Flow- based Rate Limiting

•LLDP, LLDP-MED

•Advanced Features

•Automatic Device Discovery

•Batch Configuration

•Batch Firmware Upgrading

•Intelligent Network Monitoring

•Abnormal Event Warnings

•Unified Configuration

•Reboot Schedule

•Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)

•DHCP Snooping

•IP-MAC-Port Binding

•IPv6-MAC-Port Binding

•ARP Inspection

•Radius Accounting Client MIB (RFC2620)

•Radius Authentication Client MIB (RFC2618)

•Remote Ping, Traceroute MIB (RFC2925)

•Support TP-Link private MIBs

•RMON MIB(RFC1757, rmon 1,2,3,9)

•Centralized Management

•Omada Cloud-Based Controller

•Omada Hardware Controller (OC300)

•Omada Hardware Controller (OC200)

•Firmware Upgrade: TFTP & Web

•System Diagnose: VCT

•SYSLOG & Public MIBS

•Dual Image

Stock Code: 560764

Intellinet 8-Port Fast Ethernet PoE+ Switch - 8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan, Desktop, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Intellinet 8-Port POE Desktop Switch metal case-8 x PoE ports, IEEE 802.3at/af Power-over-Ethernet (PoE+/PoE), Endspan Retail Box 2 year Limited Warranty

Product Overview
Save Installation Time and Money with PoE

The Intellinet Network Solutions 8-Port PoE+ Desktop Switch (560764) is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with eight Fast Ethernet ports (all of which support 802.3at/af PoE/PoE+), this switch can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 100 Mbps.

Power over Ethernet 802.3at
The Intellinet PoE+ Desktop Switch supports the IEEE 802.3at protocol and is designed to inject up to 30 watts of power per port*. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, thus eliminating the time and expense of electrical rewiring and minimizing the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well protected. For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest use of an Intellinet PoE/PoE+ Splitter.

* Total PoE budget for this switch is 66 watts. Per-port average power distribution is 8.25 watts; maximum per-port power usage cannot exceed 30 watts.

Stock Code: TL-SG1008P

TP-Link 8-Port Gigabit Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 8-Port Gigabit Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Expand your network with the TP-Link TL-SG1008P. This versatile switch offers four PoE+ ports to power devices like IP cameras or VoIP phones, along with standard Ethernet ports for additional connections. Its compact design and plug-and-play setup make it ideal for small offices and home networks.

Features

•8× 10/100/1000 Mbps RJ45 ports.

•4× PoE+ ports transfer data and power on the cables

•Works with IEEE 802.3af/at compliant PDs

•Plug and Play, no configuration and installation required

•802.1p/DSCP QoS enable smooth latency-sensitive traffic

•Supports PoE power up to 30 W for each PoE port

Specifications

•Product code:TL-SG1008P

•Description: TP-Link 8-Port Gigabit Desktop Switch with 4-Port PoE+

•Interface 8× 10/100/1000 Mbps RJ45 Ports

•AUTO Negotiation

•AUTO MDI/MDIX

•Network Media

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External power adapter

•(Output: 54VDC / 1.3A)

•Packet Forwarding Rate 11.904 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: ports 1–4

•Power budget for all PoE ports: 64 W

•Mac Address Table 4K

•Jumbo Frame 16 KB

•Switching Capacity 16 Gbps

•Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in

•(171×98×27 mm)

•Max Power Consumption

•5.4 W (with no PD connected)

•75 W (with 64W PD connected)

•Max Heat Dissipation

•18.4 BTU/h (with no PD connected)

•225.8 BTU/h (with 64 W PD connected)

•Transmission Method Store-And-Forward

•Compatible With IEEE 802.3af/at Compliant PDs

•IGMP Snooping

•Mac Address Auto-Learning And Auto-Aging

•IEEE802.3x Flow Control

•802.1p/DSCP QoS

Stock Code: TL-SF1009P

TP-Link 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Expand your network with the TP-Link TL-SF1009P. This versatile switch offers eight PoE+ ports to power devices like IP cameras or VoIP phones, along with a standard Ethernet port for additional connections. Its compact design and plug-and-play setup make it ideal for small offices and home networks.

Specifications

•Product code: TL-SF1009P

•Description: TP-Link 9-Port 10/100Mbps Desktop Switch with 8-Port PoE+

•9× 10/100 Mbps RJ45 Ports (8× 10/100 Mbps 802.3af/at PoE+ ports)

•AUTO Negotiation

•AUTO MDI/MDIX

•Network Media

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External Power Adapter (Output: 53.5VDC / 1.3A)

•Packet Forwarding Rate 1.3392 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: Ports 1–8

•Power Supply: 65 W

•Mac Address Table 2K

•Jumbo Frame 2 KB

•Switching Capacity 1.8 Gbps

•Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in

•(171 × 98 × 27 mm)

•Max Power Consumption

•3.6 (no PD connected)

•77.1 (with 65 W PD connected)

•Max Heat Dissipation

•12.3 BTU/h (no PD connected)

•262.8 BTU/h (with 65 W PD connected)

•Transmission Method Store-And-Forward

•Advanced Functions

•Compatible With IEEE 802.3af/at Compliant PDs

•Extend Mode Button (Ports 1–4 and Ports 1–8, Up to 250 m PoE power supply and data transmission)

•Priority Mode Button (Ports 1–2)

•Isolation Mode Button (Ports 1–8)

•Mac Address Auto-Learning and Auto-Aging

•IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure for Half-Duplex Mode

Stock Code: TL-SG105PE

TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Upgrade your network with the TP-Link TL-SG105PE. This compact switch offers four PoE+ ports, delivering power and data over a single cable for IP cameras, VoIP phones, and more. With its easy-to-use interface, you can monitor network traffic and prioritize devices effortlessly. This versatile switch is perfect for small offices, homes, and businesses seeking enhanced network performance.

Specifications

•Product code: TL-SG105PE

•Description: TP-Link TL-SG105PE 5-Port Gigabit Easy Smart Switch with 4-Port PoE+

•Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,

•IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at

•Interface Five 10/100/1000Mbps RJ45 Ports

•AUTO Negotiation/AUTO MDI/MDIX

•Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Power Supply External Power Adapter (Output: 53.5 VDC/1.3 A)

•PoE Ports (RJ45) Standard: 802.3 af/at compliant

•PoE Ports: Port 1- Port 4

•PoE Power Budget: 65 W

•Dimensions ( W x D x H ) 3.9 × 3.9 × 1.0 in (99.8 × 98 × 25 mm)

•Max Power Consumption 4.5 W (with no PD connected)

•75.2 W (with 65 W PD connected)

•Max Heat Dissipation 15.4 BTU/h (with no PD connected)

•256.3 BTU/h (with 65 W PD connected)

•Switching Capacity 10 Gbps

•Packet Forwarding Rate 7.44 Mpps

•MAC Address Table 2 K

•Packet Buffer Memory 1.5 Mb

•Jumbo Frame 16 KB

•Quality of Service Support Port-Based/802.1p/DSCP priority

•Support 4 priority queues

•Rate Limit

•Storm Control

•L2 Features IGMP Snooping V1/V2/V3

•Static Link Aggregation

•Port Mirroring

•Cable Diagnostics

•Loop Prevention

•PoE Auto Recovery

•Extend Mode

•Management Web-based GUI

•Storage Temperature: -40℃~70℃ (-40℉~158℉)

•Operating Humidity: 10%~90%RH non-condensing

•Storage Humidity: 5%~95%RH non-condensing

Stock Code: TL-SF1006P

TP-Link TL-SF1006P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link TL-SF1006P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Expand your network with the TP-Link TL-SF1006P. This versatile switch offers four PoE+ ports to power devices like IP cameras or VoIP phones, along with standard Ethernet ports for additional connections. Its compact design and plug-and-play setup make it ideal for small offices and home networks.

Features

•6× 10/100 Mbps RJ45 ports

•4× PoE+ ports transfer data and power on individual cables

•Works with IEEE 802.3af/at compliant PDs

•Up to 250m data and power transmitting range under Extend Mode**

•Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application

Specifications

•Product code: TL-SF1006P

•Description: TP-Link TL-SF1006P 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+

•6× 10/100 Mbps RJ45 Ports (ports 1–4 support 802.3af/at PoE+)

•AUTO Negotiation

•AUTO MDI/MDIX

•Network Media

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)

•Packet Forwarding Rate 0.8928 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: Ports 1–4

•Power Supply: 67 W

•Mac Address Table 2K

•Jumbo Frame 2 KB

•Switching Capacity 1.2 Gbps

•Dimensions ( W x D x H ) 6.2 x 4.0 x 1.0 in (158 x 101 x 25 mm)

•Max Power Consumption

•2.52 W (220 V / 50 Hz, no PD connected)

•75.4 W (220 V / 50 Hz, with 67 W PD connected)

•Max Heat Dissipation

•8.59 BTU/h(no PD connected)

•257.11 BTU/h(with 67 W PD connected)

•Transmission Method Store-And-Forward

•Compatible With IEEE 802.3af/at Compliant PDs

•Extend Mode Button (Ports 1–4)

•Priority Mode Button (Ports 1–2)

•PoE Auto Recovery (Ports 1-4)

•Mac Address Auto-Learning and Auto-Aging

•IEEE802.3x Flow Control For Full-Duplex Mode and Backpressure for Half-Duplex Mode

Stock Code: TL-SG1005P

TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

The TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE is an efficient networking solution that allows for data and power transmission over a single cable, making it ideal for powering devices like IP cameras and access points. It features five RJ45 ports, with four supporting Power over Ethernet (PoE) to deliver up to 15.4W per port, ensuring reliable connectivity for various applications.

Specifications

•Product code: TL-SG1005P

•Description: TP-Link 5-Port Gigabit Desktop Switch with 4-Port PoE+

•5× 10/100/1000Mbps RJ45 Ports

•AUTO Negotiation

•AUTO MDI/MDIX

•Network Media

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•External Power Supply External Power Adapter (Output: 53.5 VDC / 1.31 A)

•Packet Forwarding Rate 7.44 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: Ports 1–4

•Power Supply: 65 W

•Mac Address Table 2K

•Jumbo Frame 16 KB

•Switching Capacity 10 Gbps

•Dimensions ( W x D x H ) 3.9×3.9×1.0 in (99.8×98×25 mm)

•Max Power Consumption

•3.44 W (220/50 Hz. no PD connected)

•74.49 W (220/50 Hz. with 65 W PD connected)

•Max Heat Dissipation

•11.73 BTU/h (no PD connected)

•254.01 BTU/h (with 65 W PD connected)

•Advanced Features

•Compatible With IEEE 802.3af/at Compliant PDs

•Mac Address Auto-Learning And Auto-Aging

•IEEE 802.3x Flow Control

•802.1p/DSCP QoS

•IGMP Snooping

•Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission)

•PoE Auto Recovery (Ports 1-4)

•Transfer Method Store-And-Forward

Stock Code: TL-SF1008P

TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE+, Retail Box, 1 year Limited Warranty

Product Overview

Features

•8× 10/100 Mbps RJ45 ports

•4× PoE+ ports transfer data and power on individual cables

•Works with IEEE 802.3af/at compliant PDs

•Supports PoE Power up to 30 W for each PoE port

•Supports PoE Power up to 66 W for all PoE ports*

•Up to 250m data and power transmitting range under Extend Mode**

•Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application

Specifications

•Product code: TL-SF1008P

•Description: TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE+

•8× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports)

•AUTO Negotiation

•AUTO MDI/MDIX

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)

•Packet Forwarding Rate 1.1904 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: Ports 1–4

•Power Supply: 66 W

•Mac Address Table 2K

•Jumbo Frame 2 KB

•Switching Capacity 1.6 Gbps

•Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)

•Max Power Consumption 2.27 W (220 V/ 50 Hz. no PD connected)

•75.33 W (220 V/ 50 Hz. with 66 W PD connected)

•Max Heat Dissipation 7.74 BTU/h(no PD connected)

•256.88 BTU/h(with 66 W PD connected)

•Transmission Method Store-And-Forward

•Advanced Functions Extend Mode Button (Ports 1–4)

•Priority Mode Button (Ports 1–2)

•PoE Auto Recovery Button (Ports 1–4)

•Mac Address Auto-Learning and Auto-Aging

Stock Code: TL-SF1005P

TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Product Overview

The TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE is designed to enhance your network connectivity while providing Power over Ethernet (PoE) capabilities. It features five auto-negotiation RJ45 ports, with four supporting PoE to power devices like IP cameras and access points, delivering up to 15.4W per port.

Specifications

•Product code:TL-SF1005P

•Description: TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE

•Transmission Distance Store-And-Forward

•Interface 5 10/100Mbps RJ45 Ports

•AUTO Negotiation/AUTO MDI/MDIX

•Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•External Power Supply External Power Adapter(Output: 48VDC / 1.25A)

•PoE Ports (RJ45) Standard: 802.3af (15.4W)

•PoE Ports: Port1- Port4

•Total PoE Budget: 58W

•Mac Address Table 2K

•Switching Capacity 1Gbps

•Dimensions ( W x D x H ) 3.9 × 3.9 × 1.0 in.

•(99.8 x 98 x 25 mm)

•Max Power Consumption 1.7W (no PD load)

•64.8W (with 58W PD load)

•Max Heat Dissipation 5.7BTU/h(no PD load)

•221.2BTU/h(with 58W PD load)

•Transmission Method Store-And-Forward

•Advanced Functions Compatible With IEEE 802.3af Compliant PDs

•Priority Function

•Mac Address Auto-Learning And Auto-Aging

•IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode

Stock Code: TL-SG1005LP

TP-Link 5-Port Gigabit Desktop PoE+ Switch, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 5-Port Gigabit Desktop PoE+ Switch, Retail Box, 1 year Limited Warranty

Product Overview

The TP-Link 5-Port Gigabit Desktop PoE+ Switch features four PoE+ ports that deliver both data and power over a single Ethernet cable, supporting IEEE 802.3af/at compliant devices. It offers 30 W per port and a total of 40 W across all PoE ports, making it ideal for powering devices like IP cameras and wireless access points.

Specifications

•Product code: TL-SG1005LP

•Description: TP-Link 5-Port Gigabit Desktop PoE+ Switch,

•Interface

•5× 10/100/1000Mbps RJ45 Ports

•AUTO Negotiation

•AUTO MDI/MDIX

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•External Power Supply External Power Adapter (Output: 53.5 VDC / 0.81 A)

•Packet Forwarding Rate 7.44 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af/at compliant

•PoE Ports: Ports 1–4

•Power Supply: 40 W

•Mac Address Table 2K

•Jumbo Frame 16 KB

•Switching Capacity 10 Gbps

•Dimensions ( W x D x H ) 3.9×3.9×1.0 in (99.8×98×25 mm)

•Max Power Consumption

•4.12 W (220/50 Hz. no PD connected)

•47.5 W (220/50 Hz. with 40 W PD connected)

Max Heat Dissipation

•14.05 BTU/h (no PD connected)

•161.98 BTU/h (with 40 W PD connected)

•Advanced Features

•Compatible With IEEE 802.3af/at Compliant PDs

•Mac Address Auto-Learning And Auto-Aging

•IEEE 802.3x Flow Control

•802.1p/DSCP QoS

•IGMP Snooping

•Transfer Method Store-And-Forward

Stock Code: TL-SF1008LP

TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Product Overview

The TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE provides an easy and affordable way to expand your wired network with Power over Ethernet (PoE) capabilities. It features 8 auto-negotiation RJ45 ports with 4 PoE-enabled ports that can power and connect PoE-compatible devices like IP cameras, VoIP phones, and wireless access points.

Specifications

•Product code: TL-SF1008LP

•Description: TP-Link 8-Port 10/100Mbps Desktop Switch with 4-Port PoE

•8× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE)

•AUTO Negotiation

•AUTO MDI/MDIX

•Network Media

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External Power Adapter (Output: 53.5 V DC / 0.81 A)

•Packet Forwarding Rate 1.1904 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af compliant

•PoE Ports: Ports 1–4

•Power Supply: 41 W

•Mac Address Table 2K

•Jumbo Frame 2 KB

•Switching Capacity 1.6 Gbps

•Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)

•Max Power Consumption

•2.2 W (220 V/ 50 Hz. no PD connected)

•47.1 W (220 V/ 50 Hz. with 41 W PD connected)

•Max Heat Dissipation

•7.5 BTU/h(no PD connected)

•160.61 BTU/h(with 41 W PD connected)

•Transmission Method Store-And-Forward

•Advanced Functions

•Compatible With IEEE 802.3af Compliant PDs

•Extend Mode Button (Ports 1–4)

•Priority Mode Button (Ports 1–2)

•Mac Address Auto-Learning and Auto-Aging

•IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex Mode

Stock Code: TL-SF1005LP

TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE, Retail Box, 1 year Limited Warranty

Product Overview

The TP-Link 5-Port 10/100Mbps Desktop Switch features five RJ45 ports, with four PoE ports that deliver both data and power over a single cable, supporting IEEE 802.3af compliant devices. It provides a maximum power output of 15.4W per port, making it suitable for powering devices like IP cameras and access points.

Specifications

•Product code:TL-SF1005LP

•Description: TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE

•5× 10/100 Mbps RJ45 Ports (Ports 1–4 support 802.3af PoE)

•AUTO Negotiation

•AUTO MDI/MDIX

•10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•100BASE-TX: UTP category 5, 5e cable (maximum 100m)

•EIA/TIA-568 100Ω STP (maximum 100m)

•Fan Quantity Fanless

•Physical Security Lock Yes

•External Power Supply External Power Adapter (Output: 53.5 V DC / 0.81 A)

•Packet Forwarding Rate 0.744 Mpps

•PoE Ports (RJ45)

•Standard: 802.3 af compliant

•PoE Ports: Ports 1–4

•Power Supply: 41 W

•Mac Address Table 2K

•Jumbo Frame 2 KB

•Switching Capacity 1 Gbps

•Dimensions ( W x D x H ) 3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm)

•1.9 W (220 V / 50 Hz, no PD connected)

•47 W (220 V / 50 Hz, with 41 W PD connected)

•Max Heat Dissipation

•6.48 BTU/h(no PD connected)

•160.27 BTU/h(with 41 W PD connected)

•Transmission Method Store-And-Forward

•Compatible With IEEE 802.3af/at Compliant PDs

•Extend Mode Button (Ports 1–4)

•Priority Mode Button (Ports 1–2)

•Mac Address Auto-Learning And Auto-Aging

•Jumbo Frame 2 KB

•Switching Capacity 1 Gbps

•Dimensions ( W x D x H ) 3.9 x 3.9 x 1.0 in (100 x 98 x 25 mm)

•1.9 W (220 V / 50 Hz, no PD connected)

•47 W (220 V / 50 Hz, with 41 W PD connected)

•Max Heat Dissipation

•6.48 BTU/h(no PD connected)

•160.27 BTU/h(with 41 W PD connected)

•Transmission Method Store-And-Forward

•Advanced Functions

•Compatible With IEEE 802.3af/at Compliant PDs

•Extend Mode Button (Ports 1–4)

•Priority Mode Button (Ports 1–2)

•Mac Address Auto-Learning And Auto-Aging

Stock Code: MS105GP

Mercusys MS105 5-Port Gigabit Desktop Switch, Retail Box, 2 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Mercusys MS105 5-Port Gigabit Desktop Switch, Retail Box, 2 year Limited Warranty

Product Overview

Upgrade your network with the Mercusys MS105 5-Port Gigabit Desktop Switch, featuring five full Gigabit RJ45 ports for fast and reliable connectivity. With four PoE+ ports supporting up to 30W power each, along with extended transmission distance and isolation mode for stability and security, it offers efficient performance in a durable metal casing.

Specifications

•Product code: MS105GP

•Description: Mercusys MS105 5-Port Gigabit Desktop Switch

•Dimensions: 99.8*98*25mm

•PoE Ports : RJ45

•Standard: Compliant with 802.3 af/at Powered Devices

•PoE Ports: Port 1- Port 4

•PoE Power Budget: 65 W

•Interfaces : 5× 10/100/1000Mbps Ports, Auto-Negotiation, Auto MDI/MDIX

•External Power Supply : External Power Adapter (Output: 53.5V/1.31A)

•Installation : Desktop

•Wall Mount

•Standards and Protocols: IEEE 802.3x Flow Control

•Data Rates

•10/100/1000 Mbps at Half Duplex

•20/200/2000 Mbps at Full Duplex

•Jumbo Frame: 9 KB

•Mac Address Table : 2K

•Max Power Consumption: 3.13W（220 V / 50 Hz, no PD connected）

•75.15W（220 V / 50 Hz, with 65W PD connected）

•Max Heat Dissipation: 10.64 BTH/h （no PD connected)

•255.51 BTH/h（with 65W PD connected）

•5-Port Gigabit Desktop Switch with 4-Port PoE+(MS105GP)

•Quick Installation Guide

•Operating Temperature: 0℃~40℃ (32℉~104℉)

•Storage Temperature: -40℃~70℃ (-40℉~158℉)

•Operating Humidity: 10%~90% RH non-condensing

•Storage Humidity: 5%~95% RH non-condensing

1 to 15 of 15 items

Page 1

Photographed products shown above are for illustrative purposes only. www.esquireshop.com © 2021
