Stock Code: ME70X

Mercusys ME70X AX1800 Wi-Fi 6 Range Extender, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Mercusys ME70X AX1800 Wi-Fi 6 Range Extender, Retail Box , 1 year Limited Warranty

Product Overview

The Mercusys ME70X AX1800 Wi-Fi 6 Range Extender enhances your network with dual-band speeds of up to 1800 Mbps—1201 Mbps on 5 GHz and 574 Mbps on 2.4 GHz—leveraging Wi-Fi 6 technology for improved speed, efficiency, and capacity. It features a Gigabit Ethernet port for fast wired connections to devices like PCs and game consoles, and it easily integrates with any router to extend Wi-Fi coverage.

Specifications

•Product code: ME70X

•Description: Mercusys ME70X AX1800 Wi-Fi 6 Range Extender

•Wireless Standards

•IEEE 802.11a/n/ac/ax 5GHz, IEEE 802.11b/g/n/ax 2.4GHz

•Frequency 2.4GHz and 5GHz

•WiFi Speeds 574 Mbps at 2.4GHz, 1201 Mbps at 5GHz

•Reception Sensitivity

•5GHz:

•11ax HE80 MCS0:-88 dBm ;

•11ax HE80 MCS11:-58 dBm

•11a 6Mbps:-94 dBm;

•11a 54Mbps:-76 dBm

•11ac VHT80 MCS0:-91dBm;

•11ac VHT80 MCS9:-63dBm;

•2.4GHz:

•11ax HE40 MCS0:-93 dBm ;

•11ax HE40 MCS11:-63 dBm

•11g 6Mbps:-95 dBm;

•11g 54Mbps:-77 dBm

•11n HT40 MCS9:-72dBm;

•Wireless Security WEP, WPA, WPA2, WPA3-PSK

•Hardware Dimensions

•138.6 × 100.3 × 68.4 mm

•Interfaces 1 Gigabit Ethernet Port

•Button WPS / Reset Button

•Antenna Type 2× External Antennas

•Power Consumption 13W

Stock Code: MW325R

Mercusys MW325R 300Mbps Enhanced Wireless N Router, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Mercusys MW325R 300Mbps Enhanced Wireless N Router, Retail Box , 1 year Limited Warranty

Product Overview

The Mercusys MW325R 300Mbps Enhanced Wireless N Router delivers extensive coverage with four high-gain 5dBi antennas, providing up to 500m² of wireless range. With a maximum speed of 300Mbps, it is ideal for HD streaming, online gaming, and large file downloads, ensuring a stable connection throughout your home.

Specifications

•Product code: MW325R

•Description: Mercusys MW325R 300Mbps Enhanced Wireless N Router

•Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.4 - 2.5GHz Signal Rate

•11n: Up to 300Mbps (Dynamic)

•11g: Up to 54Mbps (Dynamic)

•11b: Up to 11Mbps (Dynamic) Reception Sensitivity

•270M: -70dBm@10% PER

•130M: -72dBm@10% PER

•54M: -74dBm@10% PER

•11M: -87dBm@10% PER

•6M: -92dBm@10% PER

•1M: -94dBm@10% PER Transmission Power <20dBm Wireless Security WPA-PSK / WPA2-PSK Wireless Functions

•Enable/Disable Wireless Radio, WDS Bridge

•SoftwareWAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP

•Management Access control

•Local management

•Remote management DHCP Server, DHCP Client List

•Port Forwarding Virtual server, UPnP, DMZ Dynamic DNS Oray Firewall Security IP and MAC address binding Protocols IPv4 Guest Network 2.4GHz guest network

•Hardware Dimensions (W X D X H) 167 x 118 x 33 mm Interfaces

•3 10/100Mbps LAN ports

•1 10/100Mbps WAN port Button Reset button External Power Supply 5VDC/0.6A Antenna Type 4 x 5dBi fixed omni directional antennas

Stock Code: MW305R

Mercusys MW305R 300Mbps Wireless N Router, Retail Box , 1 year Limited Warranty

Click Here For More Detail

Click Here For a Quick Description

Mercusys MW305R 300Mbps Wireless N Router, Retail Box , 1 year Limited Warranty

Product Overview

The Mercusys MW305R 300Mbps Wireless N Router offers reliable performance with speeds up to 300Mbps, making it perfect for HD streaming, online gaming, and large file downloads. Equipped with three 5dBi antennas, it significantly enhances wireless signal strength and stability across your home.

Specifications

•Product code: MW305R

•Description: Mercusys MW305R 300Mbps Wireless N Router,

•Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.4 - 2.4835GHz Signal Rate

•11n: Up to 300Mbps (Dynamic)

•11g: Up to 54Mbps (Dynamic)

•11b: Up to 11Mbps (Dynamic)

•Reception Sensitivity

•270M: -70dBm@10% PER

•130M: -74dBm@10% PER

•108M: -74dBm@10% PER

•54M: -77dBm@10% PER

•11M: -87dBm@8% PER

•6M: -90dBm@10% PER

•1M: -98dBm@8% PER

•Transmission Power <20dBm Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK Wireless Functions WDS bridge

•SoftwareWAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP Management

•Parental Control

•Access control

•Local management

•Remote management DHCP Server Port Forwarding Virtual server, UPnP, DMZ Dynamic DNS DynDNS、NO-IP Firewall Security IP and MAC address binding Protocols IPv4 Guest Network 2.4GHz guest network

•Hardware Dimensions (W X D X H)

•169 x 116 x 35 mm

•Interfaces 3 10/100Mbps LAN ports

•1 10/100Mbps WAN port

•Button Reset/WPS button External Power Supply 5VDC/0.6A Antenna Type 3 x 5dBi fixed omni directional antennas
