Stock Code: PRIME_Z790-P_D4

Asus PRIME Z790-P D4 LGA 1700 Motherboard - Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors, Intel Z790 Chipset, 4x DDR4 DIMM Memory Slots, 4x SATA6 Connectors, 3x M.2 Key M Connectors, On-Board Display: 1x HDMI Connector, 1x DisplayPort Connector, 1x Intel I219-V 1Gb Ethernet port, On-Board Realtek 7.1 Surround Sound High Definition Audio CODEC, 1x PCIe 5.0 x16 slot, 3x PCIe 4.0 x16 slots (support x4 mode), 1x PCIe 3.0 x1 slot, 1x USB 3.2 Gen 2x2 port (1 x USB Type-C®), 1x USB 3.2 Gen 2 port (1 x Type-A), 2x USB 3.2 Gen 1 ports (2 x Type-A), 4x USB 2.0 ports (4 x Type-A), ATX Form Factor, Retail Box, 1 year warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview

ASUS Prime series motherboards are expertly engineered to unleash the full potential of 13th Gen Intel® Core™ Processors. Boasting a robust power design, comprehensive cooling solutions and intelligent tuning options, PRIME Z790-P D4 provides users and PC DIY builders with a range of performance optimizations via intuitive software and firmware features.

Features

Outstanding Audio

•Combined onboard features deliver elevated audio.Intelligent design and premium hardware create audio quality unlike anything you’ve ever experienced.

Audio Shielding

•Audio shielding ensures precision analog/digital separation and greatly reduced multi-lateral interference.

Dedicated Audio PCB Layers

•Separate layers for left and right tracks ensures both channels deliver consistent, equal quality.

Specifications

•Product code: PRIME_Z790-P_D4

•Description: Asus PRIME Z790-P D4 LGA 1700 Motherboard

•ATX Form Factor

•Intel Z790 Chipset

•Socket LGA 1700

•4x DDR4 DIMM Slots, Supports Up To 128GB

•Supports Up to DDR4-5333MHz (OC)

•Supports Intel XMP Memory Profiles

•1x PCIe 5.0 x16 Slot

•3x PCIe 4.0 x4 Slots

•1x PCIe 3.0 x1 Slot

•2x M.2 22110 PCIe 4.0 x4 NVMe SSD Slots

•1x M.2 2280 PCIe 4.0 x4 NVMe SSD Slot

•4x SATA 3.0 6.0Gbps Ports

•1x USB 3.2 Gen 2x2 20Gbps Type-C Port

•1x USB 3.2 Gen 2 10Gbps Type-A Port

•2x USB 3.2 Gen 1 5Gbps Type-A Ports

•4x USB 2.0 Type-A Ports

•1x HDMI 2.1, 1x DisplayPort 1.4

•3x 3.5mm Audio Jacks (Line Out, Line In, Microphone)

•Realtek 2.5 Gigabit Ethernet RJ-45 LAN

Stock Code: 90MB1HE0-M0EAY0

Asus TUF Gaming B760M-PLUS WIFI II LGA 1700 Micro ATX Motherboard - Compatible with Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® , Intel® B760 Chipset, 4 x DIMM slots Memory, Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports.

Click Here For More Detail

Click Here For a Quick Description

Product Overview

The Asus TUF Gaming B760M-PLUS WIFI II is a durable microATX motherboard designed for Intel® LGA1700 socket, supporting 14th, 13th, and 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors. It features the Intel® B760 chipset, 4 DDR5 DIMM slots supporting up to 192GB memory, and robust storage options with 3 M.2 slots plus 4 SATA 6Gb/s ports. Equipped with PCIe 5.0, Wi-Fi 6E, 2.5Gb Ethernet, and comprehensive cooling solutions, it delivers stable, high-performance gaming and computing experiences.

Specifications

•Product Code: 90MB1HE0-M0EAY0
•Description: ASUS TUF Gaming B760M-PLUS WIFI II Intel LGA 1700 micro ATX Motherboard
•CPU: Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Generations, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors
•Chipset: Intel® B760 Chipset
•Memory: 4 x DIMM slots, Max. 192GB DDR5, Dual Channel Memory Architecture
•Graphics: 1 x DisplayPort, 1 x HDMI™ port and Graphics specifications may vary between CPU types.
•Expansion Slots: 1 x PCIe 5.0 x16 slot, 1 x PCIe 4.0 x4 slot, 1 x PCIe 4.0 x4 slot.
•Storage: Supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
•Ethernet: 1 x Realtek 2.5Gb Ethernet, TUF LANGuard
•Wireless & Bluetooth: Wi-Fi 6E, 2x2 Wi-Fi 6E (802.11ax), Supports 2.4/5/6GHz frequency band, Bluetooth® v5.3.
•USB: 1 x USB 20Gbps port (1 x USB Type-C®), 1 x USB 10Gbps port (1 x Type-A), 2 x USB 5Gbps ports (2 x Type-A), 4 x USB 2.0 ports (4 x Type-A)
Audio:
•Realtek 7.1 Surround Sound High Definition Audio CODEC
-Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
-Supports up to 24-Bit/192 kHz playback
•Audio Features
-Audio Shielding
-Rear optical S/PDIF out port
-Premium audio capacitors
-Dedicated audio PCB layers
•BIOS: 128 Mb Flash ROM, UEFI AMI BIOS
•Manageability: WOL by PME, PXE
•Form Factor: mATX Form Factor, 9.6inch x 9.6 inch ( 24.4 cm x 24.4 cm )
•Operating System: Windows® 11, Windows® 10 64-bit

Stock Code: PROH610M-EDDR4

MSI PRO H610M-E DDR4 LGA1700 Motherboard - Support Intel Core 14th, 13th, 12th Gen Processors, Intel Pentium Gold and Celeron Processors, Intel H610 Chipset, 2x DDR4 memory slots, support up to 64GB, 4x SATA 6Gb/s ports, 1x M.2 slots (Key M), 1x HDMI 1.4 with HDR port, supports a maximum resolution of 4K 30Hz, 1x VGA port, 6x USB 2.0 ports (2 Type-A port on the back panel, 4 ports available through internal USB 2.0 connectors), 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back panel, 2x USB 3.2 Gen 2 1.5Gbps Type-A ports, 4x USB 2.0 Type-A ports on the back panel, 1x PCIe x16 slots, 1x PCIe 3.0 x1 slot, Realtek ALC897 Codec, 1x Realtek RTL8111H 1Gbps LAN controller - m-ATX Form Factor, Retail Box, 3 year warranty

Click Here For More Detail

Click Here For a Quick Description

Product Overview

MSI PRO series motherboards help users work smarter by delivering an efficient and productive experience. Featuring stable functionality and high-quality assembly, PRO series motherboards provide not only optimized professional workflows but also less troubleshooting and longevity.

Features

•Supports 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket

•Supports DDR4 Memory, up to 3200(MAX) MHz

•Core Boost: With premium layout and digital power design to support more cores and provide better performance

•Memory Boost: Advanced technology to deliver pure data signals for the best performance, stability and compatibility

•Lightning Fast Experience: PCIe 4.0

•Audio Boost: Reward your ears with studio grade sound quality

•Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.

Specifications

•Product code: PROH610M-EDDR4

•Description: MSI PRO H610M-E DDR4 LGA1700 Motherboard

•Socket: 1700

•Chipset: Intel® H610 Chipset

•DDR4 Memory: 3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz

•Memory Channel: Dual Channel

•DIMM Slots: 2

•Max Memory (GB): 64

•PCI-E x16: 1

•PCI-E x1: 1

•SATAIII: 4

•M.2 Slot: 1

•TPM (Header): 1

•LAN: 1x Realtek® RTL8111H Gigabit LAN controller

•USB 3.2 ports (Front): 2(Gen 1, Type A)

•USB 3.2 ports (Rear): 2(Gen 1, Type A)

•USB 2.0 ports (Front): 4

•USB 2.0 ports (Rear): 4

•Audio ports (Rear): Realtek® ALC897 Codec

•VGA: 1

•HDMI: 1

•DirectX: 12

•Form Factor: mATX

Stock Code: 90MB1B40-M0ECY0

Asus Prime H610M-R D4 Intel LGA 1700 micro ATX Motherboard - Intel, Processor socket LGA 1700, Compatible processor series Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel Pentium G. Supported memory types DDR4-SDRAM, Maximum internal memory 64GB, Memory slots type DIMM. Supported storage drive interfaces M.2, SATA III, Supported storage drive types HDD & SSD. Maximum resolution 3840 x 2160 pixels. USB connector type USB Type-A.

Click Here For More Detail

Click Here For a Quick Description

Product Overview

This motherboard supports Intel processors with LGA 1700 socket, including Celeron, Pentium Gold, and 12th, 13th, and 14th Gen Core i3/i5/i7/i9 series. It features up to 64GB DDR4-SDRAM via DIMM slots, supports both HDD and SSD storage through M.2 and SATA III interfaces, and delivers crisp visuals with a maximum resolution of 3840 x 2160 pixels. Connectivity options include multiple USB Type-A ports, making it a versatile choice for modern PC builds
